75W Adjustable Prison Signal Jammer
Model: KJ-75P5
Introductions:
KJ-75P5 is Medium Power Prison Signal Jammer, KJ-75P5 uses state-of-art technology for maximum performance and reliability
Features:
Frequency bands and output power selectable
Each frequency band be controlled independently by different power adjusting snobs
Easy operation and installation
Effectively making subsections, no interception to base station
Remote Monitoring software available to control the Jammer (optional)
Applications:
Any sensitive locations where the wireless signals are not allowed, such as prisons, military bases.
Technical Specifications:
Jamming frequency bands: 4 or 5 frequency bands selectable of VHF, UHF, CDMA, GSM, 3G WCDMA, TDMA, 4G LTE, 4G WIMAX, WIFI, GPS, etc, as following one typical working bands selection:
Frequency Range Output Power
CDMA: 851-894MHz 15W
GSM: 925-960MHz 15W
DCS: 1805-1880MHz 15W
PCS: 1930-1990MHz 15W
3G: 2110-2170MHz 15W
RF output power: up to 75W
Internal Modulation: FM Hopping Frequency and Sweeping
Signal Source: PLL Synthesized & VCO
Effective jamming range: 10-100mdepending on the environment signal strength;
Jamming target: VHF, UHF, CDMA, GSM, 3G WCDMA, TDMA, 4G LTE, 4G WIMAX, WIFI, GPS, etc selectable
Remote Control: Remote Monitoring available by IP Network (optional)
Remote Control Interface: RJ45 (optional)
Power supply: 220VAC/110VAC
Continuous working hours: Long time
Antennas type: 4 to 5pcs high gain Directional LPDA antennas or Omni Antennas
Device Dimension: 560*330*270mm
Device Net Weight: 10kgs
Operating Temperature: -20ºC - +50ºC
Humidity: 5% - 95%
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() | |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
