300W High Power Portable Bomb Jammer
Model: KJ-300M6
Introductions:
The KJ-300M6 is High Power Portable Bomb jammer;
The KJ-300M6 uses state-of-art technology for maximum performance and reliability;
The KJ-300M6 has robust mechanical design, ready for use;
The system use Broadband Omni-Directional antennas for 360 degree protection.
Features and Advantages:
Frequency bands and output power selectable;
Integrated main equipment, battery, and antennas which increases mobility of the device;
Different frequency bands can be controlled independently by different switches;
Local or wire control operation mode can be selected based on actual environment;
AC or DC power supply can be selected;
Power Amplifiers protection design ensures the working reliability of the device.
Applications:
Prevent remote controlled improvised explosive devices from being activated and stop terrorist attacks;
Protect explosives handling experts;
Protect important places such as bus/train stations, plazas, schools, mass gatherings, stadiums, etc;
Risk mitigation and explosives removal in specified spots;
Police and S.W.A.T uses for VVIP convoy, ECM, anti drug, riot control, etc;
Military uses for border control, ECM etc.
Technical Specifications:
RF Characteristics:
Working frequency range: 20MHz to 6000MHz ranges selectable;
RF Output Ports: up to 6 RF Output Ports selectable;
RF output power: up to 300W;
Internal Modulation: Direct Digital Synthesis (DDS) or Analog;
Effective jamming ranges: 50-500mdepending on the environment signal strength;
Jamming target: toy remote control, car remote control, pager, Walkie Talkie, CDMA, GSM, DCS, PCS,3G, 4G, WIFI, WIMAX, etc;
Remote Control: Wire Control Panel Available (optional);
Power supply: 220VAC, 12/24/28VDC battery selectable (optional);
Continuous working hours: Long time (by AC 220V); 2hours by battery, rechargeable;
Antennas type: high gain Omni Antennas;
Physical data:
Main equipment Dimension: 630*530*330mm;
Main equipment Weight: 30kgs;
Environment of operation:
Operating Temp: -20ºC - +50ºC;
Humidity: 5% - 95%.
